CIP (Clean-In-Place) is an automated cleaning system widely used in modern beer brewing. It allows brewers to clean the internal surfaces of tanks, pipelines, heat exchangers, and other process equipment without dismantling them.
At DEGONG, we consider the CIP system a core component of any professional brewery, whether for craft-scale production or industrial beer plants. A properly designed CIP system ensures hygiene, efficiency, and consistent beer quality throughout the brewing process.
During brewing, residues such as yeast, proteins, sugars, and hop compounds easily adhere to tank walls and pipelines. If not completely removed, these residues can lead to bacterial growth, off-flavors, and batch contamination.
A DEGONG CIP system effectively eliminates these residues, ensuring:
Stable beer flavor from batch to batch
Reduced risk of microbial contamination
Longer shelf life of finished beer
Manual cleaning requires equipment disassembly, extensive labor, and long downtime. In contrast, CIP systems operate automatically according to preset parameters, significantly reducing cleaning time and labor costs.
With a DEGONG CIP solution, brewers benefit from:
Faster cleaning cycles
Reduced human intervention
Increased production uptime
CIP systems minimize direct human contact with hot water and chemical detergents. This not only improves hygiene standards but also reduces safety risks for brewery staff.
Automated CIP cleaning helps breweries:
Maintain a cleaner production environment
Reduce chemical handling risks
Comply with modern food safety practices
Modern breweries are required to meet strict hygiene and food safety standards. CIP systems provide repeatable, documented cleaning processes, including control of:
Cleaning temperature
Chemical concentration
Flow rate
Cleaning time
DEGONG CIP systems are designed to support quality audits and regulatory compliance with confidence.
A typical DEGONG CIP cleaning cycle includes the following steps:
Step 1: Pre-Rinse
Water is circulated through the system to remove loose debris and residual product.
Step 2: Caustic Cleaning
An alkaline cleaning solution removes organic residues such as proteins, sugars, and fats.
Step 3: Intermediate Rinse
Clean water flushes out remaining alkaline chemicals to prepare for the next stage.
Step 4: Acid Cleaning
An acidic solution removes mineral deposits, beer stone, and scale from internal surfaces.
Step 5: Final Rinse
Fresh water ensures that all cleaning chemicals are fully removed.
Step 6: Sanitization
The system is sanitized using chemical disinfectants or high-temperature water to eliminate microorganisms before production restarts.
4.1 Consistent and Repeatable Cleaning
Automated programs ensure that every cleaning cycle follows the same validated parameters, eliminating human error.
4.2 Reduced Water and Chemical Consumption
Optional solution recovery and reuse functions help reduce water usage and chemical costs.
4.3 Lower Risk of Cross-Contamination
Thorough and controlled cleaning significantly reduces the risk of cross-batch contamination.
When selecting a CIP system, DEGONG recommends considering the following factors:
Brewery production capacity
Number and size of tanks and pipelines
Required automation level (manual, semi-automatic, or fully automatic)
Food-grade stainless steel components
Efficient heating, pumping, and solution recovery design
A well-designed CIP system is not just a cleaning tool—it is a long-term investment in brewery performance and beer quality.
In modern beer brewing, cleanliness is non-negotiable. The CIP system plays a critical role in ensuring product safety, consistent flavor, and efficient brewery operation.
Whether you operate a small craft brewery or a large-scale beer production facility, a DEGONG CIP system provides reliable cleaning performance, operational efficiency, and peace of mind.
