Stacked Fermentation Tank And Beer Bright Tank 500 Liters 5HL Conical Fermenter Beer Stackable Tank

Are you still worried about the limited installation space of your dream brewery? Building a brewery of the right size is every brewery and beer lover's big dream. But this dream may be dashed by the limited installation space. Here we would like to share some ideas with you to help you open your dream brewery without space constraints.
Availability:
Quantity:
  • DG-500 Liter
  • DEGONG
Product Description

Stacked 500 Liters Fermentation Tank


Configurations
Top
Dome Top, with ratating CIP ball TC
Jackets
Both on Bottom and Cylinder Parts
CIP
CIP Arm with Rotating ball, Butterfly valve
Valves
Safety/Vacuum Valve
Outlet
Butterfly valve
Temp.
Thermometer and PT-100
Testing
Test:0.3Mpa, Working: 0.15-0.2Mpa
Pressure
Bung Apparatus with Pressure Gauge
Polishing
0.4-0.6μm/ or Mirror polishing
Legs
4 legs with adjustable Bolts
Cooling
Cooling ports, Threads ø25mm
Parts
With gaskets, Cooling pipe fittings


614


Items Total Volumn ID(mm) OD(mm) Height(mm) Heat Exchange Area Weight
100L
140L
500
630
1600
0.50 m2
85kg
200L 250L 600 750 1850 0.80 m2 150kg
300L 400L
650 800 2190
1.00 m2 195kg
500L 650L 800
960 2200
1.35 m2 265kg
600L 770L
800 960
2420
1.60 m2 280kg
1000L 1300L
1050
1200 2630 2.80 m2 320kg
1500L
2000L 1200 1360
2850
3.30 m2 390kg
2000L 2500L 1400 1560 2900 3.50 m2 540kg
2500L
3300L
1500 1700
3300
3.70 m2 630kg
3000L 4000L
1600 1800 3750
5.00 m2 770kg
4000L 5200L 1700 1900 4050
5.50 m2 1000kg
5000L 6400L 1800 2000 4250
6.50 m2 1150kg


592


Contact us

The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
