Ss304 Stainless Steel Horn Cleaning Ball Male Connector Rotating 14mm Horn Spray Cleaner Cleaning Ball 304 Rotating Cleaner

The horn spray ball can effectively clean the container with a diameter of 4.5m, and can wash the tank in all directions at any angle. The highest cleaning efficiency, low water consumption, energy consumption and chemical dosage, self-lubricating with cleaning fluid, connection methods with threaded, quick installation or welding, can wash the tank in all directions at any angle.
Availability:
Quantity:
  • SS304
  • DEGONG
Product Description

technical parameter:

Speed: 2-16r/min

Connection mode: pin type, internal thread, external thread

Working temperature: less than or equal to 120 degrees

Material: SUS304-316L

Nominal diameter: DN25-40

Standards: ISO, DIN, SMS

Flushing radius: greater than or equal to 2.5 meters

Working pressure: PN0.3-0.6Mpa

Spraying form: middle top spray, middle bottom spray, full spray, spray washing within 360 degrees

910

application:

  • Pharmacy tank      Beer can

  • Milk jug                 Beverage can

feature:

  • 1. The rotation is driven by the spray reaction force.

  • 2. High cleaning efficiency.

  • 3. Low water consumption.

  • 4. Various connections.

Applicable industry:

  • Hotels, clothing stores, building materials stores, manufacturing plants, machinery repair shops, food and beverage plants, farms, restaurants, construction engineering, energy and mining, food and beverage stores

5678

feature(2):

  • Effective cleaning, especially suitable for sanitary water tanks up to 4.5 meters in diameter. Very efficient cleaning function. Very low consumption of water, energy and cleaning materials. Sanitary structure, with the self-lubricating ability of cleaning fluid, which can be passed through threads, clamps, welding or bolts Connect to the water tank in all directions, spray and clean every part of the water tank.

Working criteria:

  • The spray cleaning ball automatically and powerfully sprays the cleaning fluid to clean the inside of the tank. The cleaning fluid uses its power to rotate the sprayer, and then the interesting jet makes the entire tank and the reactor vortex. Can effectively remove the medium residue on the inner surface of the container.

12

If you are interested in our products, please contact us! DEGONG is committed to creating the most sophisticated and perfect products. If you want to choose a horn-shaped spray ball, then we are your best choice.
