Spun Polypropylene Sediment Filter Cartridges

The spun polypropylene sediment filter is composed of multiple layers to achieve excellent depth filtration. The hierarchical density structure captures particles across the entire cross-section of the filter element and reduces surface binding. These filter elements combine quality and cost-effectiveness to provide superior filtration value.
Availability:
Quantity:
  • Spun Polypropylene Filter Cartridges
  • DEGONG
Product Description

Spun Polypropylene Filter Cartridges


The DEGONG spun polypropylene sediment filter is composed of multiple layers to achieve excellent depth filtration. The hierarchical density structure captures particles across the entire cross-section of the filter element and reduces surface binding. These filter elements combine quality and cost-effectiveness to provide superior filtration value. Various micron grades and sizes are available. The spun polypropylene precipitation filter complies with NSF standards.


Product parameter


Material Polypropylene
Length 9-7/8” - 40”
Maximum temperature 60°C / 140°F
Micron rating (nominal) 1 - 50
Maximum flow rate 2 - 28 gpm (2.5” diameter)
10 - 30 gpm (4.5” diameter)
Cartridge packaging Shrink wrapped


2.5” diameter


Part Number Micron Length
101 1 9-7/8”
201 1 20"
301 1 30"
401 1 40"
105 5 9-7/8”
205 5 20"
305 5 30"
405 5 40"
1025 25 9-7/8”
2025 25 20"
1050 50 9-7/8”


4.5” diameter


Part Number Micron Length
101-B 1 9-7/8”
201-B 1 20"
105-B 5 9-7/8”
205-B 5 20"
1025-B 25 9-7/8”
2025-B 25 20"

228

Feature

  • Multi-layer gradient density

  • Excellent chemical resistance

  • low cost

  • High dirt holding capacity

  • Wide range of micron grades

  • Various sizes


Application

  • Reverse osmosis prefiltration

  • Food and beverage industry

  • drinking water

  • electronic product

  • Residential

  • Fine Chemicals

  • plating

  • Metal surface treatment

  • car wash


Products Show

222225223224227


We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
