10-20 Heads Semi-automatic Sterile Air Rinse Bottle Machine (Up To 1200 Bph) Provide Various Models

10-20 Heads Bottle Rinsers

Describe

Semi-automatic machine for flushing bottles with sterile air. Equipped with 20 bottle positions. The production capacity is as high as 1,200 bottles per hour.

• 20 bottle positions on the rotating table

• Single-phase bottle flushing with sterile air

• Pneumatic lift of the blowing nozzle Compressed air

• Filter components

• Electronic sensor realizes "no bottle-no flushing" function

• Switchboard with low voltage circuit

• Equipped with an inverter to allow fine-tuning the low and maximum speed of the machine and various voltage supplies

• Installed on wheels with brakes

• The machine complies with CE regulations

• Made entirely of stainless steel AISI 304

• Standard voltage: 220V – 1ph – 50/60hz

Technical data :

– Maximum output: 1200 bph

– Installed power: 0.65 kW

– Average power consumption: 0.65 kW

– Water consumption: about 0.2 L/bottle (1200 bph = 240 lt/h)

– Machine size: L x W x H 90x90x90 cm

– Machine packaging: L x W x H 100x100x100 cm

– Machine weight: 80 Kg

– Machine packaging weight: 90 Kg

The working principle of the flusher is as follows:

– Load bottles manually on the turntable

– Sterile water rinse nozzle

– Dripping

– Unload the rinsed bottles
