DN15 304 Stainless Steel 2pc Ball Valve 1/2inch Female Threaded Ends 1000WOG Water Oil

The ball valve is driven by the valve stem and rotates around the axis of the ball valve. Especially suitable for media containing fibers, small solid particles, etc. This type of valve should generally be installed horizontally in the pipeline. According to the driving mode, the ball valve is divided into: pneumatic ball valve, electric ball valve, manual ball valve.
  • 1/2 Inch 201 NPT
Product Description

1000 WOG: Max 1000 psi for Water, Oil, Gas
Fluid Medium: For use with liquids and gases
Body & Ball Type: 304 Stainless Steel
Temp Range: -60°F to 450°F
Handle: Heavy duty handle with blue vinly insulation


1. Wear-resistant; because the spool of the hard-sealed ball valve is spray-welded alloy steel, three-piece ball valve

The sealing ring is made of alloy steel surfacing, so the hard-sealed ball valve will not produce too much wear when it is switched on and off.

2.Second, the sealing performance is good; because the sealing of the hard-seal ball valve is manually ground, it can not be used until the valve core and the sealing ring are completely matched. Therefore, its sealing performance is reliable.


The pneumatic ball valve has a simple and compact structure, reliable sealing, and convenient maintenance. The sealing surface and the spherical surface are often in a closed state, which is not easy to be eroded by the medium. It is easy to operate and maintain. It is suitable for general working media such as water, solvent, acid and natural gas. It is mainly used for cutting off. Or connect the medium in the pipeline, and can also be used for fluid adjustment and control.


DEGONG products are exported to the world, if you are interested in our NPT solenoid valve ball valve, please contact us!
