DEGONG Series 1″ Food Grade PVC Liquid Suction Hose Winery Hose

The transparent PVC structure with white helix makes it can be used as a milk suction hose as well as a delivery hose for liquid dairy products. All hose assemblies include 316 stainless steel sanitary clamp joints, with 304 stainless steel ferrules crimped at both ends.
Availability:
Quantity:
  • 1″ Winery Hoses
  • DEGONG
Product Description

1″ Winery Hoses


NOTE: -4°F (-20°C) to 150°F (+65°C)"


Feature

  • Comes fully assembled with 316 stainless steel triclamps

  • Precision controlled ID and OD dimensions facilitate the insertion of sanitary fittings

  • Food grade hose materials comply with applicable FDA(03) and 3-A(01) requirements and is approved by USDA(11) for use in meat and poultry plants

  • Transparent "see-the-flow" construction allows for visual confirmation of material flow

  • Smooth outer cover provides increased pressure rating and smooth surface for banding

  • Phthalate free

11391

Specification

  • Construction: PVC tube with rigid PVC helix

  • 304 stainless steel ferrules

  • 316 stainless steel triclamp ends

  • Service Temperature: -4°F (-20°C) to 150°F (+65°C)

  • Max pressure:75 PSI (104° = 50 PSI)


Food guide

  • Food grade liquids such as potable water, beer, wine and juice

  • Ice transfer

  • Milk and dairy product transfer

  • Water suction - standard duty

172170173

SIZE ID OD LENGTH WEIGHT W.P.
INCH MM MM M/ROLL KG/ROLL BAR
1/4" 6 11 100 11.5 10
5/16" 8 14 100 15 10
3/8" 9 15 100 17 9
3/8" 9.5 15.5 100 18.5 9
3/8" 10 16 100 20 9
1/2" 12 18 100 22 9
3/4" 19 26 50 18 8
1" 25 33 50 27 7
1-1/4" 32 41 50 40 6
1-1/2" 38 48 50 52.5 6
2" 50 62 50 80 5


153104


Our products have achieved success in the Chinese market, Europe, East Asia, and North America. The sales network is now spread all over the world, and the on-time delivery rate is 100%, satisfying customers.

We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
