Complete Brewhouse Craft Beer Brewery Equipment Turnkey Project of Brewing System Machine

Two-vessels brew house includes mash/lauter tun and kettle/whirlpool tank. Three-vessels includes mash tank, lauter tun and kettle/whirlpool tank. Four-vessels includes mash tank, lauter tun, boiling kettle and whirlpool tank. The capacity is bigger, the vessels is more. It is just in order to reduce the brewing time, improve the working efficiency.
Availability:
Quantity:
  • DGET 50-5000L
  • DEGONG
Product Description

50-5000L Complete Brewhouse


Brewhouse
50-5000L
Headspace
+30%
Heating way
Steam/Electric heating
Material
SUS304, SUS316, Red Copper
Detailed Specification
1.Insulation:rock wool
2.Insulation thickness:80mm
3.Interior Shell: SUS 304 full welded;TH=3.0mm
Exterior Shell: SUS 304 full welded;TH=2.0mm
4.Thermowell with high accuracy temperature sensor
5.Dished top and conical bottom
6.Sanitary liquid level lindicator with valves
7.Raker with motor on top with Scrape board, VFD
8.Milling sieve plate
9.Side spent grain door
10.Washing grain pipe
11.CIP 360°rotary spray device
12.Stainless steel manhole on top
13.Material: SUS304,Brushed outer shell
14.4pcs completely SUS304 heavy duty legs
15.With all matched valves and accessories
Option: glass lamp, glass manhole, grist hydrator,wort grant, hop filter.
Other special request, can be customized according for your brewhouse
Manufacture Arts
100% TIG welding with pure argon gas shield;
Interior Finish: Overall polishing to ≤0.6μm without dead corner
Inner tank inside surface fully acid washed and passivated after polishing;form protective film, easy to clean, no sanitary dead angle.


484


Item Production capacity Volume in US Gallon Heating area Tank diameter Height
DG-500 500L/day 132 US Gallon 0.5m2 1160mm 2400mm
DG-600 600L/day 158 US Gallon 0.6m2 1160mm 2500mm
DG-700 700L/day 185 US Gallon 0.7m2 1260mm 2500mm
DG-800 800L/day 212 US Gallon 0.8m2 1260mm 2500mm
DG-1000 1000L/day 264 US Gallon 1.0m2 1360mm 2800mm
DG-1500 1500L/day 396 US Gallon 1.5m2 1560mm 2900mm
DG-2000 2000L/day 528 US Gallon 2.0m2 1960mm 3150mm
DG-2500 2500L/day 660 US Gallon 2.5m2 1960mm 3200mm
DG-3000 3000L/day 792 US Gallon 3.0m2 2060mm 3800mm
DG-5000 5000L/day 1320 US Gallon 5.0m2 2260mm 4400mm


477


Contact us

The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
