DG-2000L
DEGONG
| Features |
All materials are sanitary stainless steel.
Humanized structure design, easy to operate.
The transition area of the inner wall of the tank adopts arc transition to ensure that there is no hygienic dead angle.
The storage tank capacity is 100L, 150L, 200L, 300L, 500L, 1000L, 2000L, 3000L, 4000L, 5000L,etc. Recommended external material is SUS316L
| Material | Sanitary stainless steel 304/316 |
| Volume | 50L-20000L |
| Design Pressure | 0.1Mpa~1.0Mpa |
| Heating way | By electric/by gas/by steam |
| Applicable range | Used as liquid storage tank, liquid composing tank, temporary storage tank and water storage tank etc. |
| Ideal in field such as foods, dairy products, fruit juice beverages, pharmacy, chemical industry and biological engineering etc. | |
| Structure characteristics | Made of single-layer stainless steel structure. |
| Materials are all sanitary stainless steel. | |
| Humanized structure design and easy to operate. | |
| Transition area of interior wall on tank adopts arc for transition to ensure no dead comer of sanitation. | |
| Configuration of tank | Quick open manhole. |
| Various types of CIP cleaners. | |
| Fly and insect resistant sanitary breathing cover. | |
| Adjustable triangular bracket. | |
| Dismountable materials input pipe assembly. | |
| Thermometer (According to customer requirements). | |
| Ladder (According to customer requirements). | |
| Liquid level meter and level controller (According to customer requirements ). | |
| Eddy-proof board. |
Capacity (L) | Dimension of tank （mm） | Total hight （mm） | Diameter of inlet/outlet （mm） | Motor power （kw） |
| 500 | 840*1000 | 2750 | 38 | 0.55 |
| 600 | 920*1000 | 2850 | 38 | 0.55 |
| 700 | 990*1000 | 2850 | 38 | 0.55 |
| 800 | 950*1220 | 3000 | 38 | 0.55 |
| 900 | 1010*1220 | 3000 | 38 | 0.55 |
| 1000 | 1060*1220 | 3150 | 51 | 0.75 |
| 1500 | 1160*1500 | 3350 | 51 | 0.75 |
| 2000 | 1340*1500 | 3410 | 51 | 1.1 |
| 3000 | 1410*2000 | 4000 | 51 | 1.5 |
| 4000 | 1620*2000 | 4250 | 51 | 1.5 |
| 5000 | 1810*2000 | 4300 | 51 | 2.2 |
