String Wound Polypropylene Sediment Filter Cartridges

The wire-wound polypropylene precipitation filter is made of durable polypropylene rope wrapped around a rigid polypropylene core. They are an economical solution to reduce fine deposits including sand, silt, rust and scale particles.
Availability:
Quantity:
  • String Wound Filter Cartridges
  • DEGONG
Product Description

String Wound Filter Cartridges


The filter element can separate solid particles from liquid or gas, or fully contact different material components to speed up the reaction time. So as to protect the normal operation of the equipment or make the air clean. When the medium enters the filter element with a certain specification filter. The impurities are blocked, and the clean medium comes out through the filter element. Provide a variety of micron grades and sizes to meet your application needs.


Material (media) Polypropylene fiber cord
Material (core) Polypropylene
Length 9-7/8” - 40”
Diameter 2-1/2” - 4-1/2”
Maximum temperature 74°C / 165°F
Micron rating (nominal) 1 - 50
Maximum flow rate 5 - 28 gpm (2.5” diameter)
10 - 30 gpm (4.5” diameter)
Cartridge packaging Shrink wrapped


2.5” diameter


Part Number Micron Length
101-S 1 9-7/8”
201-S 1 20"
301-S 1 30"
401-S 1 40"
105-S 5 9-7/8”
205-S 5 20"
305-S 5 30"
405-S 5 40"
1025-S 25 9-7/8”
2025-S 25 20"
1050-S 50 9-7/8”


4.5” diameter


Part Number Micron Length
101-BS 1 9-7/8”
201-BS 1 20”
105-BS 5 9-7/8”
205-BS 5 20”
1025-BS 25 9-7/8”
2025-BS 25 20”
1050-BS 50 9-7/8”
2050-BS 50 20”


Feature

  • High Flow

  • Low pressure drop

  • High dirt holding capacity

  • Wide range of micron grades

  • Wide range of length


Application

  • Residential

  • Commercial

  • Fine Chemicals

  • Metal surface treatment

  • Reverse osmosis prefiltration

  • Food and beverage industry

  • Drinking water

  • Electronic product


Products Show

231235232233


The best quality and ex-factory price Our company has always insisted: integrity management, quality first, reasonable price, and service first are the cornerstones.

You are welcome to send us inquiries and orders.
