500L Copper Alcohol Vodka Gin Still Professional Distillation Equipment Manufacturer

Our high-efficiency distillation tower can effectively rectify and purify the distillate, and can easily achieve an alcohol concentration of up to 96% vol. At any desired level of purity. The integrated high-pressure flushing system can effectively clean the entire distillation unit.
Availability:
Quantity:
  • DEGONG-500L
  • DEGONG
Product Description

Copper Alcohol Vodka Gin Still


Parameter
Working capacity 100-5000L
Total Volume working capacity*130%-150%
Voltage 200V-240V/380-440V/600V
Weight 500kg-5000kg
Material SUS3048/SUS316L/COPPER-C12200
Welding Technolog High purity argon arc welding
Heating Method Steam/Electric
Heating form Direct or indirect heating
Distillation method Liquid distillation by default, custom solid distillation can be customized
Running time 2-8h,Customizable continuous distillation
Shape Upper and lower heads/Customizable
Distilled products Gin/Whisky/Vodka/Brandy/Tequila/Rum/Bourbon
Optional module 1.Cooling water recycling system
2.Light system
3.Alcohol storage tank system(Head/Heart/Tail)

71


Features
  • Optimize the distillation tower for high-quality fractions

  • Flexible modular system, free to combine components.

  • The integrated high-pressure flushing system can effectively clean the entire distillation unit.

  • The three-way ball valve can be used to make the distillation equipment multi-functional, and different spirits can be made according to customer needs.

  • Copper catalytic converter technology guarantees the reduction of unwanted acid content and the content of cyanide and urethane.

  • Our high-efficiency distillation tower can effectively rectify and purify the distillate, and can easily achieve an alcohol concentration of up to 96% vol. At any desired level of purity.

  • Coordinated fine distillation bottom with maximized copper contact surface. This continuously further developed design ensures the desired flavor spread and separation from unwanted ingredients

70


How distillation works

Column distillation stems from the success of tank distillation. By the 19th century, commercial distillers were looking for a faster method of distillation (each batch of distiller must be cleaned). Robert Stein and Aeneas Coffey respectively invented and improved the "column distillation" process, which actually involves huge light-emitting columns (they can reach floor heights). In tower distillation, mash or scrubbing liquid is continuously injected into the tower, and steam rises continuously to meet it. The steam is set at the perfect temperature to remove alcohol from the washing liquid and leave unwanted compounds as it rises through the column. Column distillation not only does not require cleaning between batches, the structure of the column (and the ability to have multiple columns for continuous flow and refining of alcohol vapor) allows for efficient, repetitive distillation-this is why column distillation is more efficient than pot distillation Produces a more neutral, higher ABV spirit.

Likewise, no matter how you distill, alcohol will never evaporate alone. Homologs (tannins, esters, fusel alcohols, and even methanol) will evaporate. Cutting is the process of separating these elements out of the distiller, usually through careful temperature and time control. For example, methanol evaporates at 148.5 F, so the distiller can conclude that any liquid that appears before 173 F (the safe and pleasant boiling point of ethanol) should be discarded. At the same time, fusel (also called "fusel oil" due to its oily texture) may appear at the end or "end" of the distillation run and is often discarded (or sent back for re-distillation). The basic cycle of distillation can be divided into "front", "head", "heart", "tail"-also called "score"-the heart is the most ideal component.


68


Contact us

A wide range of models can meet the various requirements of each market and ensure that you can always find a solution that suits you. If you want to know more detailed information about our equipment, please contact us.
