500L Brewpub Micro Brewery Equipment SUS304 Craft Beer Brewing System Brewhouse Machine

The 500L beer brewing system is tailor-made for users with each batch of 500L and 1 to 2 batches per day. We plan and design a complete medium-sized brewery, and all systems can be customized for the defined process based on customer input.
Availability:
Quantity:
  • DG-500L
  • DEGONG
Product Description

500L Beer Brewing Equipment


Configuration
1. 200kg/h Crashing System
2. 500L Mashing system + 1,000L Hot Water Tank
3. 500L Fermentation Tank & BBT
4. PID Control System (Optional: PLC)
5. 1,500L Glycol Cooling System
6. 50L CIP System
  • Provide installed pipelines, including valves and sensors

  • Integrated pump system

  • CIP system: separated tank CIP to prevent cross product interference

  • Customized PID / PLC (HMI touch screen, optional) control system

  • Stairs and platforms combine the container in a compact location unit, and the segmented structure of the surface walking ensures non-slip

  • The entire brewery system is installed on a complete platform, easy to move, load and unload, turnkey solution


14


Fermenters for craft beer brewing equipment
  • Function: Use for keep wort fermentation or maturation.

  • Component: It is consisted of Shadowless manhole, spunding valve, Aseptic valve, Pressure gauge, Rotate racking arm, Butterfly valve, Solenoid valve and etc.

  • Capacity: effective volume is 100L-30000L, 1BBL-300BBL

  • Cooling method: dimple plate or glycol cooling jacket around tank.

  • Cooling media: glycol water or alcohol water.

  • Design pressure is 0.3MPa; Working pressure is 0.15MPa.( Our standard design, MPa can be customized).


BBT for craft brewery beer maturation and storage
  • Function: After fermenting, beer will be stored in BBT for carbonation and serving.

  • Component: It is consisted of Shadowless manhole, Mechnical relief valve, Aseptic valve, Pressure gauge, spunding valve, Butterfly valve, Solenoid valve, carbonation stone and etc.

  • Capacity: effective volume is 100L-30000L, 1BBL-300BBL

  • Cooling method: dimple plate or glycol cooling jacket around tank.

  • Cooling media: glycol water or alcohol water.Design pressure is 0.3MPa; Working pressure is 0.15MPa.( Our

  • standard design, MPa can be customized).


1816


25


Contact Kate

We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
