500L 2 Vessels Mashing System Beer Brewing Equipment Microbrewery Equipment for Sale

The brewery has a variety of vessel combinations, of course to achieve the same four steps of mashing, filtration, boiling, swirl, through the brewery's special brewing intent, including wort yield, wort specific gravity, jetting water, brewing for a certain period of time, brewing method etc.
Availability:
Quantity:
  • DG-500L

  • DEGONG

Product Description

2 Vessels Brewing Equipment


Brewhouse unit Mash/Lauter tun Grain rake with VFD
Laser cutting V-wire False Bottom
Easy clean and detachable sparging spray ring
Steam Jacket heating
Boil /whirlpool tun Steam Jacket on bottom
Steam vent with condensate ring for kettle stack


173

DEGONG 500L brewery equipment


1000L Fermentation Tank

Nominal volume  [l]

1000
Internal diameter [mm] 950
Height H [mm] 1500
External diameter [mm] 1050
Geometrical volume [l] 1250
Min. operating press. [barg] 0
Max. operating pressure [barg] atmospheric
Use Beer fermentation and maturation

186

DEGONG 1000L fermentation tanks


Cold Water Tank

Nominal volume [l] 1200
Internal diameter [mm] 1110
Height H [mm] 1250
Height Z [mm] 2070
External diameter [mm] 1210V
Min. operating press. [barg] 0
Max. operating pressure [barg] atmospheric
Use Water preparation

185

Cold water tank with double jacket


Contact us

The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
