500L 1000L Fermentation Tanks Double Stacked Jacketed Fermenter Supplier

Double stacked jacketed fermenter,which can make full use of the height of brewery room,Suitable for the section structure of the brewing factory with limited rooms.Oval manhole outside the fermenter,Pressure regulating valve, mechanical pressure regulating valve, temperature sensor, etc. are available, and can be customized according to customer needs.
Availability:
Quantity:
  • DG-500L
  • DEGONG
Product Description

500L Fermentation Tanks


Model DG-500L
Capacity Useful capacity: 500L;Gross capacity: 670L
Material SUS304
Application Restaurant, bar, hotel, brewery
Out size Ø1010*2100mm
Thickness Inner: 3.0mm; External: 2.0mm
Outrigger Ø102mm*4
Test pressure 0.2Mpa
Working pressure 0.09Mpa
Heat exchange area 1.8m2
Weight 300kg


218


Technical Parameter
  • Cylindrical, top domed with conical bottom.

  • Material Inner (SUS304)thickness: 3.0mm; Outer(SUS304)thickness:2.0mm

  • External-Jacket(SUS304) thickness: 1.5mm;

  • Oval head cone bottom, thickness: 3.0mm.

  • Equipment with : cone 60°resist compression design

  • 100% TIG welding with pure argon gas shield

  • Interior Finish: Sanitary 2B finish, Pickled and Passivity; (8K Mirror finish optional)

  • Exterior Finish: Oil brushed finish(2B, 8K Mirror finish optional)

  • Interior full polished to 0.6 μm without dead corner

  • Insulated with high density Polyurethane foam 100mm

  • Glycol Jacket: Dimpled plate on cone and side

  • Stringent tank leakage test by water and pressured gas

  • Stringent Jacket leakage test by water and pressured gas

  • Sanitary side mounted manway with pressured door

  • TC connected CIP arm with 360° coverage spraying ball

  • CO2 blow-off arm with butterfly valve

  • Full sanitary metallic sealed sampling valve

  • Hydraulic shock pressure gauge on CIP arm

  • Rotating racking arm and port on cone with butterfly valve

  • Tri-clamp discharge arm with butterfly valve

  • Thermowell for high accuracy temperature sensor

  • 4pcs completely SUS304 heavy duty legs with leveling pad and legs support

  • Complete valves, fittings and all parts

  • Kindly note: we also can based on your demand to customize the fermentation tanks for you.


221


More Volume Choice

Fermentation Tank Series

Volume in US Gallon

Diameter

Height

100L Fermentation Tank

26US Gallon

620mm

1600mm

300L Fermentation Tank

79US Gallon

960mm

1900mm

500L Fermentation Tank

132US Gallon

1010mm

2100mm

800L Fermentation Tank

211US Gallon

1060mm

2550mm

1000L Fermentation Tank

264US Gallon

1210mm

2550mm

2000L Fermentation Tank

528US Gallon

1560mm

3100mm

3000L Fermentation Tank

793US Gallon

1760mm

3500mm

4000L Fermentation Tank

1057US Gallon

1760mm

4050mm

5000L Fermentation Tank

1321US Gallon

1760mm

4540mm


202
