DEGONG-3000L
DEGONG
3000L Conical Fermentation Tanks
Beer cans are containers for beer production. In the brewing tank, water, grain, hops and yeast are brewed into a delicious beer. The principle of brewing beer is very simple, but regardless of the brewing scale, the brewing process needs to be summarized in practice. DEGONG provides custom-designed beer fermentation tanks, bright tanks and other beer tanks required by breweries from 100L to 5000HL.
Product Parameters
| Product Specifications | 100L-5000L |
| Fermentation Space | 20-30% upper fermentation space |
| Polyurethane Insulation Thickness | 60~120mm |
| Shape | Butterfly top/cylinder/60° and 70° conical bottom (can be customized as required) |
| Jacket Position | One or more side/bottom |
| Welding Method | TIG welding process |
| Inside The Tank | Mirror-polished |
Fermentation Tank Configuration
| Fermentation System | Fermentation tank | -Pressure:3 Bar -Inner:3mm; outer:2mm; with insulation -Cooling jackets |
| Accessories | Yeast Saving Tank | |
| Cooling System | Glycol water tank | -Inner:3mm; outer:2mm |
| Accessories | Chiller; Glycol water pump; Pipes & Valves | |
| CIP System | Acid tank, Caustic tank, Trolley | -Pump; Pipes & Valves-Accessories of the CIP System |
| Item | Production capacity | Volume in US Gallon | Heating area | Tank diameter | Height |
| DG-500 | 500L/day | 132 US Gallon | 1.8m2 | 1160mm | 2300mm |
| DG-600 | 600L/day | 158 US Gallon | 2.0m2 | 1220mm | 2350mm |
| DG-700 | 700L/day | 185 US Gallon | 2.4m2 | 1260mm | 2380mm |
| DG-800 | 800L/day | 212 US Gallon | 2.5m2 | 1260mm | 2400mm |
| DG-1000 | 1000L/day | 264 US Gallon | 2.6m2 | 1360mm | 2500mm |
| DG-1500 | 1500L/day | 396 US Gallon | 3.2m2 | 1520mm | 2900mm |
| DG-2000 | 2000L/day | 528 US Gallon | 3.6m2 | 1560mm | 2850mm |
| DG-2500 | 2500L/day | 660 US Gallon | 3.8m2 | 1650mm | 3200mm |
| DG-3000 | 3000L/day | 792 US Gallon | 4.5m2 | 1760mm | 3800mm |
| DG-4000 | 4000L/day | 1057 US Gallon | 4.9m2 | 1900mm | 4100mm |
| DG-5000 | 5000L/day | 1320 US Gallon | 7.2m2 | 1960mm | 4400mm |
Our advantage
1. Professional manufacturing factory
2. Good quality and service control system, produced by skilled workers
3. Design according to customer requirements
4. Timely and effective delivery
5. Flexible payment methods.
Contact us
We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
