3/4" Flexible Air Water Fuel Oil Delivery Multi Purpose Rubber Hose

Mainly used in machine tool, automobile, engineering machinery, motorcycles on the high-pressure hose, brake oil pipe and the oil, chemical, pharmaceutical, metallurgical and other industrial automatic control in the pneumatic instrument line and so on.
Availability:
Quantity:
  • 3/4" Fuel Oil Delivery Hose
  • DEGONG
Product Description

3/4" Fuel Oil Delivery Hose


SAE 100 R1 AT /DIN EN 853 1SN HYDRAULIC HOSE
Inner Tube:oil resistant synthetic rubber
Reinforcement:One high tensile steel wire braid
Cover :abrasion and weather resistant synthetic rubber
Temperature Range:-40°C to +100°C

微信图片_20211109091921微信图片_20211109091910

Hose ID
Hose OD
Working Pressure
Burst pressure
Minimum Bend Radius
Weight
inch
mm
mm
MPA
PSI
MPA
PSI
mm
kg/m
3/16
4.8
11.8
25.0
3630
100
14280
90
0.19
1/4
6.4
13.4
22.5
3270
90
12840
100
0.21
5/16
7.9
15.0
21.5
3120
85
12280
115
0.24
3/8
9.5
17.4
18.0
2610
72
10280
130
0.33
1/2
12.7
20.6
16.0
2320
64
9180
180
0.41
5/8
15.9
23.7
13.0
1890
52
7420
200
0.45
3/4
19.0
27.7
10.5
1530
42
6000
240
0.58
1
25.4
35.6
8.8
1280
35
5020
300
0.88
1-1/4
31.8
43.5
6.3
920
25
3600
420
1.23
1-1/2
38.1
50.6
5.0
730
20
2860
500
1.51
2
50.8
64
4.0
580
16
2280
630
1.97

微信图片_20211109091845


hydraulic hose assembly made according to customer's need.
We fix the connectors for you before the shipment,then you can use it directly.
The high pressure hose is mainly used for Mine hydraulic support ,oilfield exploitation ,object construction,lifting transport,metallurgic forging ,mine equipment, ship, injection molding machinery,agricultural machinery , all kinds of machine tools andvarious industrial sectors.
Machanization and automation in the hydraulic system of conveying with a certain pressure(high pressure) and the temperature of the oil-based(such as mineral oil, soluble oil, hydraulic oil, fuel oil and lubricants) and water-based liquid (such as Emulsion,the oil-water emulsion, water) and liquid transmission used.The maximum working pressure-resistant up to 70-100MPa.

微信图片_20211109091902微信图片_20211109091852

If you are interested in any of our products, please contact us.
