20inch PES Membrane Pleated Filter Element for Beer And Wine

Microporous membrane filters and filter elements are currently popular internationally microporous filtration equipment: it uses composite folded microporous membranes as the filter medium to filter certain particles through the micropores on the membrane surface, with high efficiency and good filtrate quality.
Availability:
Quantity:
  • DEGONG-20inch
  • DEGONG
Product Description

20inch Membrane Filter Cartridges


Product Paramenters
Filter Media Option
PP
PES
Nylon 6/66
PVDF
PTFE
Length
2.5'', 5, 10, 20, 30, 40 inch
2.5'', 5, 10, 20, 30, 40 inch
2.5'', 5, 10, 20, 30, 40 inch
2.5'', 5, 10, 20, 30, 40 inch
2.5'', 5, 10, 20, 30, 40 inch
Micron Rate
0.1, 0.2, 0.45, 0.65, 0.8, 1, 2, 3, 5, 10, 20, 25, 30, 50, 60 micron
0.1, 0.2, 0.45, 0.65 micron
0.2, 0.45, 0.65, 1 micron
0.2, 0.45 micron
0.2, 0.45 micron
End Cap
DOE, 222+Fin, 222+Flat, 226+Fin, 226+Flat
Inner Diameter
28mm
Outer Diameter
69mm (can be customized)
Gasket/O ring material
Silicon/EPDM/NBR/Viton/Teflon
Effective filtration area
0.4-0.7m²
≥0.6m²
≥0.6m²
≥0.72m²
≥0.72m²
Max.working pressure difference
0.42Mpa at 25ºC
0.42Mpa at 25ºC
0.42Mpa at 25ºC
0.42Mpa at 25ºC
0.42Mpa at 25ºC
Max.back pressure
0.28Mpa at 60ºC
0.21Mpa at 25ºC
0.35Mpa at 25ºC
0.21Mpa at 25ºC
0.35Mpa at 60ºC
Max. working temperature
88ºC at 0.28Mpa,         60ºC at 0.42Mpa
140ºC at 0.28Mpa
49ºC at 0.21Mpa
80ºC at 0.173Mpa
142ºC at 0.276Mpa
Sterilizing temperature
121℃, 30mins
121℃, 30mins
121℃, 30mins
121℃, 30mins
121℃, 30mins

113

Filter media selection

PP (polypropylene)

The filter adopts the folding type, the membrane filtration area is large, and the dirt holding capacity is large

Pressure reduction, long service life

The integral filter is made of 100% pure PP material, which has a wide range of chemical compatibility

Optional for a wide range of filtering precision


PES (Polyethersulfone)

Has good high temperature resistance, acid resistance and alkali resistance

The filter membrane has good hydrophilicity and large flux

No media fall off, meeting the requirements of the pharmaceutical and food industries


Nylon

Nylon grease is hydrophilic and does not require pre-wetting

Uniform pore size distribution, filtering effect

Good high strength, good chemical compatibility, wide applicability

No fiber shedding, meeting the requirements of the pharmaceutical industry


PVDF (Polyvinylidene Fluoride)

The filter is hydrophobic, which ensures absolute sterilization under wet or dry conditions. 100% of the phages are filtered in the gas.

High temperature resistance, repeated online high-pressure steam sterilization, high strength, impact resistance

Antioxidant, can be used for ozone disinfection


PTFE (Polytetrafluoroethylene)

The membrane has strong hydrophobicity, which can ensure absolute sterilization under wet or dry conditions, and 100% removal of bacteriophages in the gas.

High temperature resistance, impact resistance, corrosion resistance

The initial pressure difference is small, the air flow is large, and the service life is long

114

Our advantage

1. Professional manufacturing factory

2. Good quality and service control system, produced by skilled workers

3. Design according to customer requirements

4. Timely and effective delivery

5. Flexible payment methods.

116115

Contact us

We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
