2000L Stainless Steel Mixing Tanks
DEGONG
2000L Stainless Steel Mixing Tanks
Model (L) | Inner Diameter (φmm) | Jacket Diameter (φmm) | Motor Power (kw) | Stirrer Speed (r.p.m) |
30 | 400 | 500 | 0.6 | 60-100 |
50 | 500 | 600 | 0.8 | 60-100 |
100 | 550 | 65 | 1.1 | 60-100 |
150 | 600 | 700 | 2.2 | 60-100 |
200 | 650 | 750 | 2.2 | 60-100 |
300 | 800 | 900 | 3 | 60-100 |
500 | 900 | 1000 | 3 | 60-100 |
800 | 1100 | 1200 | 4 | 60-100 |
1000 | 1200 | 1300 | 4 | 60-100 |
1500 | 1300 | 1400 | 4 | 60-100 |
2000 | 1400 | 1500 | 5.5 | 60-100 |
2500 | 1400 | 1500 | 7.5 | 60-100 |
3000 | 1400 | 1500 | 7.5 | 60-100 |
3500 | 1400 | 1500 | 7.5 | 60-100 |
4000 | 1500 | 1600 | 7.5 | 60-100 |
5000 | 1600 | 1700 | 7.5 | 60-100 |
6000 | 1800 | 1900 | 15 | 60-100 |
18000 | 2000 | 2100 | 15 | 60-100 |
32000 | 3000 | 3200 | 37 | 35-59 |
Products Show
Application
Food and beverage industry: blending oil, seasoning sauce, fruit juice, wine, dairy products, etc.
Pharmaceutical industry: oral liquid, ointment, emulsion, petrolatum, cleaning and disinfecting liquid and other liquid paste materials.
Daily chemical industry: shampoo, milk foam, facial cleanser, sunscreen, laundry detergent, hand sanitizer, detergent, skin cream, toothpaste, conditioner, etc.
Industrial chemicals: white latex, adhesives, paints, chemical cleaning agents, chemical liquid additives, chemical solutions, new polymer liquid materials.
Feature
The stirrer seal adopts imported sanitary mechanical seal or magnetic stirring seal stirring device, and the stirring speed is optional.
The container is made of heat-resistant thermal insulation material, anti-aging polyurethane foam or pearl cotton.
The nozzle has a liquid level meter port (static pressure, capacitance, non-contact, ultrasonic, glass tube), breathing air, thermometer (digital display or dial type), CIP cleaning port, sight glass, depending on the situation to avoid light ( As an endoscope optical integration), SIP sterilization port, liquid inlet and sanitary manhole.
The interface adopts the international standard ISO quick chuck, the inner tank is made of imported stainless steel SUS316L or SUS304, the inner surface is mirror polished to Ra≤0.4m, and the outer surface is cast with matte, bright, matte sandblasted or cool colors.
Packing details
According to your needs for packaging.
