2000L Beer Conical Fermentation Tank High Quality Stainless Steel Fermenter

This beer fermenter is designed for micro craft beer brewing systems. It can be widely used in the brewing of various craft beers. The tank body is cylindrical with a cone bottom, also known as a cone tank, which is very convenient for yeast recovery and cleaning. At the same time, a rotating cleaning ball is installed in the top of the tank, which is connected to the CIP cleaning system to clean the inner wall of the tank 360 degrees to ensure hygienic and safe production.
Availability:
Quantity:
  • DG-2000L

  • DEGONG

Product Description

2000L Beer Conical Fermenter


Specification

Working capacity: 2000L

Inner diameter: custom

PU insulation: 80-100mm

Outer diameter: custom

Thickness: Inner Shell: 3mm, Dimple Sheath: 1.5mm, Cladding: 2mm


Fermenters include
  • Upper manhole or silhouette less manhole

  • Rack port with trefoil butterfly valve

  • Drain port with three-leaf butterfly valve

  • 2 clover outlets with butterfly valve

  • CIP Arm and Spray Ball

  • Sampling valve

  • Pressure gauge

  • Safety valve

  • Thermowell

  • Can be customized according to your special requirements


331


Technical Features
  • Total volume: 2850L; Effective volume: 2000L.

  • All AISI-304 stainless steel or copper construction

  • Jacket and Insulation

  • Dual zone pit cooling jacket

  • Dish top and 60° tapered bottom

  • 4 stainless steel legs with leveling ports


329

328


Contact Kate

The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
