1T/H Water Softening Equipment

1T/H Water Softening Equipment

Equipment introduction

Water softening equipment, as the name implies, is a device that reduces water hardness. It mainly removes calcium and magnesium ions in the water. When the water is deep well water or the water source is very hard, the function of using softened water equipment is to remove calcium and magnesium in the water. The ion content reduces calcium and magnesium ions in the water. In the process of softening water, water softening equipment cannot reduce the total salt content in the water. It is widely used in hot water boiler systems, heat exchange systems, industrial cooling systems, central air conditioning systems and other water equipment systems.

Fundamental

In the case of deep well water or high hardness of the water source, the function of using softened water equipment is to remove the calcium and magnesium ions in the water and reduce the calcium and magnesium ions in the water. If there is no water softener or the water softener fails, the concentration of calcium and magnesium salts on the surface of the reverse osmosis membrane will rise sharply and form insoluble precipitates, which will block the pores of the reverse osmosis membrane, shorten the service life of the reverse osmosis membrane and increase equipment Maintenance costs.

Work requirements

Inlet pressure: 0.2-.04MPa

Working temperature: 1-55℃, raw water hardness ≤6mmol/L

Operation mode: automatic/manual, water hardness ≤0.03mmol/L

Regeneration agent: industrial salt, regeneration method: countercurrent/downstream

Exchanger: 001*7 strong acid ion exchange resin

Control method: time/flow Working power supply: 220V/50HZ

Work process

The working process of the water softener is generally composed of the following steps: backwashing, salt absorption (regeneration), slow flushing (replacement), and fast flushing. All processes of different softened water equipment are very similar, but due to the actual process or the need for control, there may be some additional processes. Any water softening equipment based on sodium ion exchange is developed on the basis of these five processes.

Contact us

We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
