1inch Beer Can Assembly SS316L 3A Stainless Steel Sophisticated Craftsmanship Sanitary Sampling Valve

A sampling valve is a valve used to obtain a sample of the medium in a pipeline or equipment. In many occasions that require frequent chemical analysis of the medium sample, a special sampling valve is often used. According to the working principle or performance of sampling, sampling valves are mainly divided into three types, including double-opening valves, flanged clamp valves, and sampling valves with insulation jackets.
Availability:
Quantity:
  • 1 Inch
  • DEGONG
Product Description


Product Name

Brewery tank components SS316L   1" 3A sample clamp ss sanitary sampling valve

Material

SS304 or SS316L

Size

1/4", 3/8", 1/2" or   3/4"

Gasket

Silicone or EPDM

Connection

Clamp, Weld, Thread

Operation

Manual

Working Pressure

0-6 Bar

Working Temprature

0-130 ℃

5556


Double open valve:

The double-opening valve is a commonly used sampling valve, usually composed of two connected ball valves, and is characterized by safe and stable sampling.


Flange Clip Valve:

The principle of the flange clamp valve is to seal through the cone on the top of the valve stem and the cone hole of the valve seat. When sampling, use the handwheel to raise the position of the valve stem and separate the valve stem from the cone hole. The medium can then flow into the external sampling vessel.


52


  • Application: General

  • Medium temperature: normal temperature

  • Power: manual

  • Media: Water

  • Product name: stainless steel sampling valve

  • Structure: sampling

  • Usage: food and beverage

  • Gasket: PTFE

  • Body material: stainless steel 316L


5354


Degong products are sold all over the world. If you are interested in our check valves, please contact us!
