1inch 1/2 Inch Female Male Nickel Plated Brass Ball Valve PN25 with Red Steel Handle NPT

The brass ball valve is mainly used for cutting off, distributing and changing the flow direction of the medium. The ball valve designed as a V-shaped opening also has a good flow adjustment function. The brass ball valve is evolved from the cock. Its opening and closing part is used as a sphere, which uses the sphere to rotate 90o around the axis of the valve stem to achieve the purpose of opening and closing.
Availability:
Quantity:
  • 1 inch NPT

  • DEGONG

Product Description
Product name
600WOG brass ball valve female-male F/M
Material
Brass
Size
1/2", 3/4", 1", 1 1/4", 1 1/2"
Surface
Nickel plated
Thread standard
BSP / NTP
Use
Water, gas, solvent, oil
MOQ
1000pc


2425


Features:

1. Simple structure, relatively small size, light weight and easy maintenance.

2. Good sealing performance

3. It is suitable for frequent operation, opening and closing quickly and lightly.

4. It is not restricted by the installation direction, and the flow direction of the medium can be arbitrary.

5. Small fluid resistance.


27

Item: Ball valve size: 1/4"-4"                                                 Ball material: chrome plated

Brass material: 59-3                                                              Brass valve base material: brass

Handle material: IRON / AL                                                  Surface treatment: nickel plating

Handle type: lever                                                                Temperature: 20°C to +120°C

Stem type: explosion-proof                                                  Working pressure: 30bar/435psi port

Stem material: brass                                                             All features: Thread standard

Seat material: PTFE                                                               Body sealing material: PTFE


26


28

Degong products are sold all over the world. If you are interested in our NPT solenoid valve brass valve, please contact us!
