|Capacity ||Cylinder (OD x H) ||OAH ||Inner Thickness |
|7BBL ||1050 x 950mm ||1910mm ||3mm |
|10BBL ||1100 x 1350mm ||2360mm ||3mm |
|15BBL ||1300 x 1500mm ||2610mm ||3mm |
|20BBL ||1350 x 1750mm ||2910mm ||3mm |
|30BBL ||1500 x 2100mm ||3340mm ||3mm |
|40BBL ||1700 x 2100mm ||3420mm ||3mm |
|50BBL ||1750 x 2450mm ||3800mm ||3mm |
|60BBL ||1800 x 2800mm ||4160mm ||3mm |
|80BBL ||2100 x 2600mm ||4250mm ||3mm |
|100BBL ||2200 x 2950mm ||4650mm ||3mm |
Our Brite cans range from 1 barrel to 100 barrels, with an average headspace of 10%.
All tanks have a disc-shaped top and bottom, cylinder block.
All storage tanks are made of certified stainless steel, with 100% TIG welded joints and seams, and have a sanitary internal polish.
Dimple plate jacket for glycol cooling and high efficiency polyurethane foam insulation.
All storage tanks are connected by Tri-clamp with a design pressure up to 14.7 PSI and tested at 30 PSI.
We can customize any tank to meet the space and height constraints of your brewery.
1. Professional manufacturing factory
2. Good quality and service control system, produced by skilled workers
3. Design according to customer requirements
4. Timely and effective delivery
5. Flexible payment methods.
We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
