15BBL Sanitary Beer Brewing Equipment Beer Brite Tank

The Brite water tank is made of 304 stainless steel and manufactured in accordance with high quality standards. All our Brite tanks are pressure tested in the factory and are 100% hygienic welding.
Availability:
Quantity:
  • DEGONG-15BBL
  • DEGONG
Product Description

15BBL Beer Brite Tank


Features Include

  • 15 PSI (1 bar) working pressure

  • Side manway door for cleaning

  • 1.5" Tri-clamp carbonation stone

  • 1.5" Tri-clamp pressure gauge

  • 1.5" Tri-clamp dial face bi-metal, easy-read analog thermometer

  • 1.5" Tri-clamp Perlick-style sample valve

  • 2" Tri-clamp pressure/vacuum relief

  • 2" Center bottom tri-clamp drain

  • Sight-glass for reading volumes

  • Dedicated pipe system with 4" Tri-clamp center top opening and 1.5" tri-clamp rotating CIP spray ball for easy cleaning

  • 3/4" NPT glycol ports

36

Specification

Tank height 93"
Tank diameter 58"
Empty weight 1,014 pounds
Workload 15 barrels
Total volume 18 barrels
Exterior shell 2mm
Interior shell 3mm
Insulation material PU
Insulation TH 80mm
Top type Dished head
Manhole Type Side
Manhole size 530x430mm
Inner cone 60 degree
CIP pipe Diameter Φ38
CIP ball(1) 360º Rotating spray ball
Temperature sense PT100 sensor
Thermowell diameter Φ10
Inner Polishing 0.2-0.4micron
Design pressure 0.3Mpa
Cooling type Dimple cooling jacket
Cooling areas 6.95㎡
Cooling jacket inlet NPT1
Cooling jacket outlet NPT1
Pressure control Mechanical pressure relief valve
Pressure gauge 1pc
Rotating Racking arm 1pc
Sample port 1pc
Drain outlet 1pc

28

Features

  • 304 stainless steel

  • The tank is designed for 15 psig

  • Flange and top top and bottom

  • Bottom and side gravure cooling jacket designed for 35 psig

  • Perlick Sampling Cock

  • Carbonized mouth

  • Side placed in / raised sidewalk

  • Pressure / vacuum safety valve

  • Pressure gauge assembly

  • CIP arm fixed 316SS spray ball

  • Organic Glass Level Meter at the Top and Bottom Edge of Unicom

  • Polished stainless steel pins with adjustable feet

  • The side walls and the bottom are insulated


More displays

29263231


Our advantage

  • Professional manufacturing factory

  • Good quality and service control system, produced by skilled workers

  • Design according to customer requirements

  • Timely and effective delivery

  • Flexible payment methods.


Contact us

We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
