1500L 15HL Hotel Beer Brewing System Automatic Brewhouse Turnkey Brewery Equipment

To make the best beer possible, the craft industrial beer brewing equipment hamer mill is the key. On the basis of absorbing European advanced and experienced beer machinery technology, Our Brew house can fulfill various industrial beer brewing equipment hamer milling technologies, variable tastes or specific capacities. The Brewhouse can be heated with Steam, Electric etc. The system composed of Mash Tun , Lauter Tun, Brew Kettle, Whirlpool Tank etc. The four tanks can be combined together to meet different requirement of industrial beer brewing equipment hamer mill system.
Availability:
Quantity:
  • DG-1500L
  • DEGONG
Product Description

15HL Hotel Beer Brewing System


To make the best beer possible, the craft industrial beer brewing equipment hamer mill is the key. On the basis of absorbing European advanced and experienced beer machinery technology, Our Brew house can fulfill various industrial beer brewing equipment hamer milling technologies, variable tastes or specific capacities. The Brewhouse can be heated with Steam, Electric etc. The system composed of Mash Tun , Lauter Tun, Brew Kettle, Whirlpool Tank etc. The four tanks can be combined together to meet different requirement of industrial beer brewing equipment hamer mill system.


All the tanks certified stainless steel material for all tanks, with 100% TIG welded joints and seams with sanitary interior polish.  All tanks use Tri-clamp connections, are designed for up to 14.7 PSI and tested at 30 PSI.


And we can custom fabricate any tank to meet your building’s space and height.


1500l beer brewing system
Main system Components
Malt Milling System Malt Mill
Grain screw conveyor
Brewhouse Mash/Lauter Tun
Kettle/WhirlpoolTun
Hot liquid tank
Plate heat exchanger
Pumps
Stiring device (optional)
Other accessories: 1. operating plateform; 2. pipelines between above vessels and devices; 3. areation device; 4. butterfly valves; 5. sight glass used on pipes.
Fermenting System Fermentation Tank
Yeast adding tank (optional)
Bright beer tank (optional)
Cooling System Cold Water Tank (optional)
Glycol tank
Chiller
Pump
Relative pipes and fittings between above vessels and
devices
CIP System Acid tank
Alkali tank
Water tank
Pumps
Relative pipes and fittings between above vessels and
devices
Control  System Brewhouse control panel
Fermenting system control panel
Cooling system control panel


894895


1500L fermentation tanks
  • 1500L Net capacity, 25% head space

  • Diameter 1400mm*Height 2900mm.

  • SUS 304 material insulated tank.

  • 100% TIG welding with pure argon gas.

  • 0.3 Mpa test pressure. 0.2 Mpa working pressure.

  • Dimple cooling jacket, side and cone of the tank. NPT connection.

  • Top relief valve(PVRV), Top dry hopping port.

  • Sanitary side manway (top for option).

  • Sample valve. Pressure valve, Co2 relief valve, DIN/TC racking arm.

  • 60 degree cone.carbonation stone,

  • Level tube, CIP pipe, Blow Off pipe,

  • 24V solenoid valve.Dial Thermometer. RTD sensor.

  • Stainless steel 304 butterfly valve.(DIN, Tri-clamp)


864866


Contact us

The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
