DEGONG-1500L
DEGONG
| Product Introduction |
1500L Microbrewery or minibrewery is usually suitable for independently owned breweries that are much smaller than large corporate breweries. The characteristics of this beer brewery are usually emphasizing flavor and brewing technology. We provide small breweries (small breweries) with a production rate of 500 liters (5hl) to 3500 liters (35 hl) per brew.
Craft beer is more and more popular because it contains yeast and is good for digestion.
| 1500L Pub Beer Brewing Equipment Specification |
| Output/Brew | 15HL |
| Brew/Week | 6～12 |
| Output/Week | 90~ 180HL |
| Electric Supply | 3phase/380(220, 415,440…)v/50 (60)Hz Single Phase/ 220(110, 240…)v/50(60)Hz |
| Heating Source | Steam/Electric heating |
| Area Request | >100M2 |
Note: 1hl=100liter; 1Gallon=3.7854liter; 1Barrel (BBL) =117Liter;
| 1500L Pub Beer Brewing Equipment Configuration |
| General specification for 1500L brewery equipment | |||
| Name | Components | Capacity | Specification |
| Grain Milling Unit | Rolling Miller | 500~800kg/hr | Double roller |
| Power:3Kw | |||
| Noise:45±3db | |||
| Brewhouse Unit | Mash/Lauter tun | 1500L (total 1875L) | Side mounted grain outdoor with grain chute |
| Laser cutting V-wire False Bottom | |||
| Kettle/Whirlpool Tun | 1500L (total1560L) | Steam heating | |
| Tangential whirlpool inlet | |||
| Sanitary leveling sight glass | |||
| Hot water tank | 1500L (total1950L) | Sanitary leveling sight glass | |
| Yeast feeder | 30L | Tri clamp aeration port with ball valve | |
| Heat exchanger | 15M2(Effective area) | Completely 304 SS Corrugated plates | |
| Pump | 3M3x2PCS | ABB, Sanitary SUS304, VFD control | |
| Pipe and fittings | As design | completely SS304, Work Platform is included | |
| Fermentation unit | Fermenter | 3000L(total 3750L) | Dimple cooling jacket on cone and bottom |
| Side manway | |||
| Tri clamp CIP ball | |||
| 60 degree cone bottom | |||
| Perlick style full sanitary sampling valve | |||
| Carbonation port and level tube for special request | |||
| Filtration unit(optional) | Kieselguhr Filter | 1000kg/hr | Power:2.5w |
| Filter Area: 2.4M2 | |||
| SUS304 | |||
| Bright beer tank | Bright beer tank | 3000L(total 3600L) | Dimple cooling jacket on cone and bottom |
| Level tube for checking | |||
| Tri clamp CIP ball | |||
| Side manway | |||
| Perlick style full sanitary sampling valve | |||
| Carbonation port with tri clmap carbonation stone | |||
| Glycol Chilling Unit | Glycol Water Tank | 3000L(total 3300L) | Insulated conical top and sloped bottom |
| Chiller | 8HPx2PCS | Cooling Capacity: 15400Kcal/8HP | |
| Installed Power:7.8kw | |||
| Refrigerant: Freon R404A ,R410A | |||
| Noise:70-80db | |||
| Coperland compressor | |||
| PPR/UPVC/Stainless steel pipe | As designed | Solenoid valves for glycol inlet to tanks are included | |
| Glycol water pump | 3M3 | Sanitary SUS304, VFD control | |
| Control unit | Brewing and fermetation process Controlling | Floor type | PLC control with touch screen for special |
| PC or mobile remote control for special request | |||
| CIP | Caustic Tank | 200L | electric heating element inside, With bimetal thermometer |
| Sterilization Tank | 200L | H2O2 | |
| Pump | 3M3 | VFD control | |
| Keg cleaning | Double Station Keg Rinser | 40-60kegs/hr | Heating: Electric, Power: 15kw(steam for optional) |
| Keg filling | Single Station Keg Filler | 30-40kegs/hr | Input Power: 0.1 kw |
| Bottling line | 8 heads | 400-500 bottles/hr | Manual |
| Others | Option | Can be Customized | Auger System |
| Grain Case | |||
| Grist Hydrator | |||
| Piping flow panel for Brewhouse | |||
| Brewhouse Separate PLC Controller | |||
DEGONG is one of the professional manufacturers of home brewing products in China. To export high-quality products, we also have a professional sales team. We all have great enthusiasm. We are willing to provide our customers with the best service. They are also friends. Therefore, if you choose DEGONG, you will not be disappointed in us. If you do business with us, you will feel very at ease.
| Contact us |
We can customize product specifications according to your requirements. If you have any needs or questions, please contact us.
