DG-1000L
DGONG
Product name: Food Storage Tanks
Brand: DEGONG
Material: 304(L) 316(L)
Surface treatment: mirror or matte polishing; Ra<0.8um
Scope of application:
Sanitary storage tanks are used as liquid storage tanks, liquid dispensing tanks, temporary storage tanks, water storage tanks, etc. Be applicable
In food, dairy products, fruit juice drinks, pharmaceuticals and other fields, chemical industry, biological engineering, etc.
Structural features:
Single-layer stainless steel structure.
All materials are sanitary stainless steel.
Humanized structure design, easy to operate.
The transition area of the inner wall of the tank adopts arc transition to ensure hygiene without dead ends.
DEGONG 500L Food Storage Tanks
| Work Volume | Dimension of tank | Total height | Insulated layer | Diameter of inlet&outlet |
| (L) | (mmxmm) | (mm) | (mm) | (mm) |
| 500 | 840*1000 | 2300 | 60 | 38 |
| 600 | 920*1000 | 2400 | 60 | 38 |
| 700 | 990*1000 | 2400 | 60 | 38 |
| 800 | 950*1220 | 2550 | 60 | 38 |
| 900 | 1010*1220 | 2700 | 60 | 38 |
| 1000 | 1060*1220 | 2700 | 60 | 51 |
| 2000 | 1340*1500 | 2750 | 60 | 51 |
| 3000 | 1410*2000 | 3500 | 60 | 51 |
| 5000 | 1910*2000 | 3850 | 60 | 51 |
| 10000 | 2300*2440 | 4500 | 60 | 51 |
| 15000 | 2530*3000 | 5200 | 60 | 51 |
| 20000 | 2640*3660 | 5800 | 60 | 51 |
500L Stainless Steel Cosmetics Storage Tanks
| Contact us |
The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
