1000L Commercial Whiskey Distillery Copper Distilling Equipment Vodka Column Still

Each piece of equipment is designed for a specific purpose. The distiller specifically designed for whiskey promotes reflux, prevents foam from reaching the column plate, and continues to transfer as much flavor as possible from the mash. On the other hand, the distiller for vodka should be designed to transmit as little wort flavor as possible.
Availability:
Quantity:
  • DG-1000L
  • DEGONG
Product Description

1000L Vodka Column Still


Production Standard
  • All signs & wording in English

  • All tanks to be supplied with Data Plates including Test Data & Serial Number

  • All tanks will be tested and inspected in the NDT room after construction & Quality Control Checks

  • All jackets will be tested using water pressure testing, testing pressure: 0.4Mpa (4 Bar) & working pressure : 0.2 Mpa (2 Bar)

  • All tanks will be pressure tested for 48hours before leaving the MICET factory;

  • All the welds are full TIG welded by water spray method to ensure uniform weld pattern with full pickling & passivation

  • All tanks are mirror polishing inside, to be Ra 0.4um.

  • All Gaskets are manufactured with EPDM


394



The importance of copper distiller and thick copper

A copper pot of high quality and excellent workmanship should still be designed to last 15-20 years. The use, maintenance and cleaning of the distiller are essential to prolong the service life of the copper distiller.


Most commercial copper still manufacturers use 1/8” to 3/16” thick copper for their equipment. At DEGONG, we use thicker copper to extend the service life. We use ¼” copper for the key parts of our tank stills (twice as thick as most other suppliers).


The thickness of the copper used to make the pot distiller is an important factor affecting the service life of the distiller. The copper in the distiller plays an important role (removing sulfur from the steam), but it will also degrade and weaken over time, which will affect the service life of the distiller.


In short, the thicker the copper (all other things being equal), the longer the distiller will run as designed.


414


Contact us

The special attention we give in the final quality inspection of each work is also a guarantee of unparalleled reliability and robustness. If you have any needs or questions, please contact us.
