100 Feet DEGONG Series Standard Wall PVC Food And Beverage Vacuum/transfer Hose

Standard wall food and beverage grade vacuum/transfer hose with rated working pressures. Crystal clear PVC compound, formulated with ingredients in compliance with applicable FDA1 requirements, meets USDA2, 3A3 and NSF4 criteria and California Proposition 65. Reinforced with helically-wound spring steel wire.
Availability:
Quantity:
  • 100 Feet PVC Food Grade Suction Hoses
  • DEGONG
Product Description

100 Feet PVC Food Grade Suction Hoses


Service Temperature Range: 25°F (-4°C) to 150°F (65°C)

92

Teature

  • Spiral wire reinforcement prevents kinking or collapsing ... hose diameter will not expand under normal rated working pressures

  • Crystal clear - allows visual confirmation of product flow

  • Glass-smooth interior reduces material buildup

  • Electro-galvanized helical steel wire can be used for static dissipation when the metal wire is properly connected to ground, through the fitting or other means

  • Resistant to chemicals

  • Self-extinguishing

  • Non-marking

  • Non-toxic

  • Silicone-free

  • 29.9" HG vacuum rating

  • Phthalate Free as of 4/10/15

9085

Specification

Hose ID Hose OD Max PSI @ 70°F Max PSI @ 122°F Min Bend Radius Coil Length
1/4" 0.46" 150 70 1" 100'
3/8" 0.6" 100 70 1 1/2" 100'
1/2" 0.75" 100 70 2" 100'
5/8" 0.891" 100 50 2 1/2" 100'
3/4" 1.03" 70 50 3" 100'
1" 1.29" 70 35 4" 100'
1 1/4" 1.6" 70 35 5" 50'
1 1/2" 1.86" 50 30 6" 50'
2" 2.39" 50 30 8" 50'
2 1/4" 2.75" 50 30 9" 50'
2 1/2" 3" 50 30 10" 50'
3" 3.5" 50 30 12" 50'
120

Food guide

Apple (Sauce Or Juice) Flour Pineapple Juice
Barley Fruit Pulps Potatoes
Beer Fruit Juices Prune Juice
Beet-Sugar Honey Raisins
Brine Jelly Shortening
Brussel Sprouts Lard Oil Soft Drinks
Butter Lemon Juice Soybean Oil
Cane Sugar Mayonnaise Spinach
Castor Oil Milk Sugar
Catsup Molasses Tomato Juice
Cheese Oats Tomato Puree & Paste
Cherries Orange Juice Vegetable Oils
Corn Oil Peaches Vinegar
Eggs (Yolks Or Whites) Peanut Butter Wines
Fish Solubles Peas Yogurt


116


We can customize product specifications according to your requirements, please contact us if you need.
