1 Inch 1/2 Inch Sanitary Stainless Steel Double Clip Rotating Spray Ball/rotating Shampoo

Hygienic cleaning ball is mainly used for tank equipment in food processing, beverage, beer, pharmaceutical and other industries to clean the inside of the tank powerfully. Remove all materials gathered on the tank wall to ensure that the tank is sterile. Then, economical cleaning methods should be used in the shortest possible time. For this reason, the cleaning ball is divided into a rotating cleaning ball, a fixed cleaning ball and a rotating cleaning device.
Availability:
Quantity:
  • 1 Inch
  • DEGONG
Product Description

4


Specification: 1"-2.5", DN15-DN50

Flushing radius: greater than or equal to 2.5 meters

Material: 304, 316L

Speed: 2-16r/min

Working temperature: less than or equal to 120 degrees

Connection: welding, quick installation, screw type, pin type

Working pressure: PN0.3-0.6Mpa

Standards: ISO, DIN, SMS

Spraying form: middle top spray, middle bottom spray, full spray, spray washing within 360 degrees

32

9

Cleaning ball category:

  • Rotary cleaner: Multi-position jet type, all jet nozzles rotate during operation

  • Rotary cleaning ball: the ball is oval and round, and the spray port is flat groove shape

  • Fixed cleaning ball: 360-degree spray, 180-degree spray, spray aperture 2.5MM

87


Product Name: Sanitary cleaning spray ball
Description: Designed according to 3A standard, widely used for transfer viscous media in the food-processing, cosemtics and pharmaceutical industries
Construction: Rotary, Fixed,Double Rotary
Material: SS304/SS316L/1.4301/1.4404
Capacity: Diameter19-63MM
Surface treatment: Mirror polished and Matt polished
Availably connection: Clamp, Thread Butt weld, Flange
Availably standard: DIN, SMS, 3A, RJT, ISO/IDF


If you are interested in our products, please contact us! DEGONG is committed to creating the most sophisticated and perfect products. If you want to choose a dual card fixed spray ball, then we are your best choice.
