1/4" High Quality Flexible Textile Reinforced Rubber Fuel Oil Petroleum Suction Delivery Hose with Helix Steel Wire

This delivery hose assembly is a high-quality solution designed for gravity feeding and low-pressure pumping devices. The fuel hose is suitable for petroleum and diesel applications and is available in a variety of lengths to meet your requirements.
Availability:
Quantity:
  • 1/4" Fuel Oil Delivery Hose
  • DEGONG
Product Description

1/4" Fuel Oil Delivery Hose


微信图片_20211109091917


INCH Hose I.D Hose O.D Working Pressure Minimum Bend Radius Test pressure Min.Bend Radius Hose Weight
(MM) (MM) (Mpa) (Bar) (Psi) (Mpa) (Bar) (Psi) (Bar) (mm) (gr/m)
1/4 6.3 13.2 50 500 7250 200 2000 29000 1000 40 192
5/16 8 15.2 45 450 6525 180 1800 26100 900 50 225
3/8 10 17.5 42.5 425 6162 170 1700 24650 850 80 345
1/2 13 21.5 35 350 5075 140 1400 20300 700 90 378
5/8 16.4 24.5 22.5 225 3262 90 900 13050 450 100 459
3/4 19.5 28 20.5 200 2900 80 800 11600 400 130 505
1 25.4 35 17.5 175 2573 70 700 10150 350 150 645.5

7

10

9

Packaging Details

50m/roll*20roll - 90*90*50CM wooden box;
50m/roll*100roll -130*90*100CM wooden box;hydraulic hose hydraulic hose 2"
300m/roll woven bags packed in rolls for hydraulic hose manufacturer motorcycle hydraulic hose hydraulic hose


Product Applications

Mainly used in machine tool, automobile, engineering machinery, motorcycles on the high-pressure hose, brake oil pipe and the oil, chemical, pharmaceutical, metallurgical and other industrial automatic control in the pneumatic instrument line and so on.


If you are interested in any of our products, please contact us.
